Code No. |
D |
R |
B |
L |
d |
|
1270 01 4 + |
9.5 |
2.5 |
9.0 |
49.0 |
# 6.35 |
|
(3/8) |
(3/32) |
(11/32) |
(1 15/16) |
(1/4) |
|
|
1270 02 4 + |
12.7 |
3.0 |
9.5 |
48.0 |
6.35 |
|
(1/2) |
(1/8) |
(3/8) |
(1 7/8) |
(1/4) |
|
|
1270 04 4 + |
19.1 |
3.0 |
9.5 |
51.0 |
6.35 |
|
(3/4) |
(1/8) |
(3/8) |
(2") |
(1/4) |
|
|
1270 06 4 + |
22.0 |
5.0 |
12.0 |
55.0 |
6.35 |
|
(7/8) |
(13/64) |
(15/32) |
(2 3/16) |
(1/4) |
|
|
1270 08 4 + |
28.6 |
8.0 |
14.0 |
58.0 |
6.35 |
|
(1 1/8) |
(5/16) |
(9/16) |
(2 5/16) |
(1/4) |
|
|
1270 08 8 + |
28.6 |
8.0 |
14.0 |
67.0 |
12.7 |
|
(1 1/8) |
(5/16) |
(9/16) |
(2 5/8) |
(1/2) |
|
|
1272 02 4 * |
12.7 |
3.0 |
9.5 |
48.0 |
6.35 |
|
(1/2) |
(1/8) |
(3/8) |
(1 7/8) |
(1/4) |
|
|
1272 04 4 ** |
19.1 |
3.0 |
9.5 |
51.0 |
6.35 |
|
(3/4) |
(1/8) |
(3/8) |
(2") |
(1/4) |
|
|
1272 06 4 *** |
22.0 |
5.0 |
12.0 |
55.0 |
6.35 |
|
(7/8) |
(13/64) |
(15/32) |
(2 3/16) |
(1/4) |
|
|
1272 08 4 **** |
28.6 |
8.0 |
14.0 |
58.0 |
6.35 |
|
(1 1/8) |
(5/16) |
(9/16) |
(2 3/16) |
(1/4) |
|
|
1272 08 8 **** |
28.6 |
8.0 |
14.0 |
67.0 |
12.7 |
|
(1 1/8) |
(5/16) |
(9/16) |
(2 5/8) |
(1/2) |
# All these marked tools are available also with 8mm shank.
* 011
** 013
*** 022
**** 019
+ Tools without Ball Bearings.
