Code No. |
D |
R |
B |
L |
d |
|
1170 01 4 |
19.1 |
6.35 |
12.7 |
41.0 |
# 6.35 |
|
(3/4) |
(1/4) |
(1/2) |
(1 5/8) |
(1/4) |
|
|
1170 04 4 |
22.2 |
7.9 |
14.3 |
43.0 |
# 6.35 |
|
(7/8) |
(5/16) |
(9/16) |
(1 11/16) |
(1/4) |
|
|
1170 07 4 |
25.4 |
9.5 |
15.9 |
44.5 |
# 6.35 |
|
(1") |
(3/8) |
(5/8) |
(1 3/4) |
(1/4) |
|
|
1170 03 8 |
15.9 |
4.8 |
11.1 |
49.0 |
12.7 |
|
(5/8) |
(3/16) |
(7/16) |
(1 15/16) |
(1/2) |
|
|
1170 01 1 8 |
19.1 |
6.35 |
12.7 |
51.0 |
12.7 |
|
(3/4) |
(1/4) |
(1/2) |
(2") |
(1/2) |
|
|
1170 04 8 |
22.2 |
7.9 |
14.3 |
52.4 |
12.7 |
|
(7/8) |
(5/16) |
(9/16) |
(2 1/16) |
(1/2) |
|
|
1170 07 8 |
25.4 |
9.5 |
15.9 |
54.0 |
12.7 |
|
(1") |
(3/8) |
(5/8) |
(2 1/8) |
(1/2) |
|
|
1170 10 8 |
34.9 |
12.7 |
25.4 |
63.5 |
# 12.7 |
|
(1 3/8) |
(1/2) |
(1") |
(2 1/2) |
(1/2) |
|
|
1170 13 8 |
44.5 |
15.9 |
31.8 |
70.0 |
# 12.7 |
|
(1 3/4) |
(5/8) |
(1 1/4) |
(2 3/4) |
(1/2) |
|
|
1170 17 8 |
50.8 |
19.1 |
36.5 |
75.0 |
12.7 |
|
(2") |
(3/4) |
(1 7/16) |
(2 15/16) |
(1/2) |
# All these marked tools are available also with 8mm shank.
