Code No. |
D |
R |
B |
L |
d |
|
1090 014 |
15.9 |
1.6 |
7.9 |
46.0 |
# 6.35 |
|
(5/8) |
(1/16) |
(5/16) |
(1 13/16) |
(1/4) |
|
|
1090 04 4 |
19.1 |
3.2 |
9.5 |
49.0 |
# 6.35 |
|
(3/4) |
(1/8) |
(3/8) |
(1 15/16) |
(1/4) |
|
|
1090 05 4 |
20.7 |
4.0 |
9.5 |
49.0 |
# 6.35 |
|
(13/16) |
(5/32) |
(3/8) |
(1 15/16) |
(1/4) |
|
|
1090 07 4 |
22.2 |
4.8 |
12.7 |
51.0 |
# 6,35 |
|
(7/8) |
(3/16) |
(1/2) |
(2") |
(1/4) |
|
|
1090 10 4 |
25.4 |
6.35 |
12.7 |
51.0 |
# 6.35 |
|
(1") |
(1/4) |
(1/2) |
(2") |
(1/4) |
|
|
1090 13 4 |
28.6 |
7.9 |
13.5 |
52.0 |
# 6.35 |
|
(1 1/8) |
(5/16) |
(17/32) |
(2 1/16) |
(1/4) |
|
|
1090 16 4 |
31.8 |
9.5 |
15.9 |
55.5 |
# 6.35 |
|
(1 1/4) |
(3/8) |
(5/8) |
(2 3/16; |
(1/4) |
|
|
1090 19 4 |
38.1 |
12.7 |
19.1 |
57.0 |
# 6.35 |
|
(1 1/2)) |
(1/2) |
(3/4) |
(2 1/4) |
(1/4) |
|
|
1 090 01 8 |
15.9 |
1.6 |
7.9 |
57.0 |
12.7 |
|
(5/8) |
(1/16) |
(5/16) |
(2 1/4) |
(1/2) |
|
|
1090 04 8 |
19.1 |
3.2 |
9.5 |
59.0 |
12.7 |
|
(3/4) |
(1/8) |
(3/8) |
(2 5/16) |
(1/2) |
|
|
1090 05 8 |
20.7 |
4.0 |
9.5 |
59.0 |
12.7 |
|
(13/16) |
(5/32) |
(3/8) |
(2 5/16) |
(1/2) |
|
|
1090 07 8 |
22.2 |
4.8 |
12.7 |
62.0 |
12.7 |
|
(7/8) |
(3/16) |
(1/2) |
(2 7/16) |
(1/2) |
|
|
1090 10 8 |
25.4 |
6.35 |
12.7 |
62.0 |
12.7 |
|
(1") |
(1/4) |
(1/2) |
(2 7/16) |
(1/2) |
|
|
1090 13 8 |
28.6 |
7.9 |
13.5 |
62.0 |
12.7 |
|
(1 1/8) |
(5/16) |
17/32) |
(2 7/16) |
(1/2) |
|
|
1090 16 8 |
31.8 |
9.5 |
15.9 |
65.0 |
12.7 |
|
(1 1/4) |
(3/8) |
(5/8) |
(2 9/16) |
(1/2) |
|
|
1090 19 8 |
38.1 |
12.7 |
19.1 |
67.0 |
12.7 |
|
(1 1/2) |
(1/2) |
(3/4) |
(2 5/8) |
(1/2) |
|
|
1090 20 8 |
41.3 |
14.3 |
20.0 |
69.0 |
12.7 |
|
(1 5/8) |
(9/16) |
(25/32) |
(2 23/32) |
(1/2) |
|
|
1090 22 8 |
44.5 |
15.9 |
22.2 |
71.0 |
12.7 |
|
(1 3/4) |
(5/8) |
(7/8) |
(2 13/16) |
(1/2) |
|
|
1090 25 8 |
50.8 |
19.1 |
25.4 |
73.0 |
12.7 |
|
(2") |
(3/4) |
(1") |
(2 7/8) |
(1/2) |
|
|
1090 26 8 |
57.1 |
22.2 |
29.4 |
78.0 |
12.7 |
|
(2 1/4) |
(7/8) |
(1 5/32) |
(3 7/16) |
(1/2) |
|
|
1090 28 8 |
63.5 |
25.4 |
31 .8 |
81 .0 |
12.7 |
|
(2 1/2) |
(1") |
(1 1/4) |
(3 3/16) |
(1/2) |
|
|
1090 30 8 ! |
69.9 |
28.6 |
34.9 |
84.0 |
12.7 |
|
(2 3/4) |
(1 1/8) |
(1 3/8) |
(3 5/16) |
(1/2) |
|
|
1090 31 8 ! |
76.3 |
31.8 |
38.1 |
87.0 |
12.7 |
|
(3") |
(1 1/4) |
(1 1/2) |
(3 7/16) |
(1/2) |
|
|
1090 33 8 ! |
82.5 |
34.9 |
41.3 |
90.5 |
12.7 |
|
(3 1/4) |
(1 3/8) |
(1 5/8) |
(3 9/16) |
(1/2) |
|
|
1090 34 8 ! |
88.9 |
38.1 |
44.5 |
94.0 |
12.7 |
|
(3 1/2) |
(1 1/2) |
(1 3/4) |
(3 11/16) |
(1/2) |
# All these marked tools are available also with 8mm shank.
! 18000 MAX RPM
