Code No. |
D |
a |
B |
L |
d |
|
1040 15 4 O |
6.35 |
7° |
8.0 |
63.5 |
# 6.35 |
|
(1/4) |
(5/16) |
(2 1/2) |
(1/4) |
||
|
1040 24 4 O |
8.0 |
9° |
9.5 |
63.5 |
# 6.35 |
|
(5/16) |
(3/8) |
(2 1/2) |
(1/4) |
||
|
1040 01 4 |
9.5 |
9° |
9.5 |
41 3 |
# 6.35 |
|
(3/8) |
(3/8) |
(1 5/8) |
(1/4) |
||
|
1040 04 4 |
12.7 |
14° |
12.7 |
44.5 |
# 6.35 |
|
(1/2) |
(1/2) |
(1 3/4) |
(1/4) |
||
|
1040 85 4 |
13.2 |
13° |
13.0 |
55.0 |
6.35 |
|
(17/32) |
(17/32) |
(2 3/16) |
(1/4) |
||
|
1040 07 4 |
15.9 |
7° |
15.9 |
44.5 |
6.35 |
|
(5/8) |
(5/8) |
(1 3/4) |
(1/4) |
||
|
1040 15 8 O |
6.35 |
7° |
8.0 |
63.5 |
127 |
|
(1/4) |
(5/16) |
(2 1/2) |
(1/2) |
||
|
1040 24 8 O |
8.0 |
9° |
9.5 |
63.5 |
12.7 |
|
(5/16) |
(3/8) |
(2 1/2) |
(1/2) |
||
|
1040 01 8 |
9.5 |
9° |
9.5 |
54.0 |
12.7 |
|
(3/8) |
(3/8) |
(2 1/8) |
(1/2) |
||
|
1040 04 8 |
12.7 |
14° |
12.7 |
60.0 |
12.7 |
|
(1/2) |
(1/2) |
(2 3/8) |
(1/2) |
||
|
1040 36 8 |
14.0 |
5° |
19.1 |
64.0 |
12.7 |
|
(9/16) |
(3/4) |
(2 7/2) |
(1/2) |
||
|
1040 07 8 |
15.9 |
7° |
15.9 |
59.0 |
127 |
|
(5/8) |
(5/8) |
(2 5/16) |
(1/2) |
||
|
1040 10 8 |
159 |
7° |
22.2 |
650 |
127 |
|
(5/8) |
(7/8) |
(2 9/16) |
(1/2) |
||
|
1040 37 8 |
15.9 |
5° |
25.4 |
68.0 |
127 |
|
(5/8) |
(1") |
(2 11/16) |
(1/2) |
||
|
1040 13 8 |
19.1 |
7° |
22.2 |
650 |
12.7 |
|
(3/4) |
(7/8) |
(2 9/76) |
(1/2) |
||
|
1040 16 8 |
19.1 |
14° |
19.1 |
650 |
12.7 |
|
(3/4) |
(3/4) |
(2 9/16) |
(1/2) |
||
|
1040 19 8 |
22.2 |
7° |
22.2 |
60.0 |
12.7 |
|
(7/8) |
(7/8) |
(2 3/8) |
(1/2) |
||
|
1040 22 8 |
22.2 |
14° |
22.2 |
66.7 |
12.7 |
|
(7/8) |
(7/8) |
(2 5/8) |
(1/2) |
||
|
1040 25 8 |
25.4 |
14° |
25.4 |
69.5 |
12.7 |
|
(1") |
(1") |
(23/4) |
(1/2) |
||
|
1040 05 3 |
14.7 |
12° |
14.3 |
58.0 |
# 60 |
# All these marked tools are available also with 8mm shank.
O Solid Carbide
